News

SMS-gateways Polygator: boxed G8/G20 and GSM-boards PCI/PCI-e

SMS-gateways Polygator: boxed G8/G20 and GSM-boards PCI/PCI-e

SMS-gateways Polygator are able to provide full-featured processing of Incoming/Outgoing SMS, delivery reports and USSD-commands support. Standalone SMS-gateway G8/G20 enables from 4 to 24 SIM-cards available in GSM-network concurrently. By using PCI/PCI-e GSM-boards it is possible to achieve much more SIM-cards per one device ratio. Currently SMS-gateways Polygator support following protocols and scenarios (but not limited to):





SMPP (Device as SMPP-server. Receive/Send SMS)
- single SMPP login/pass per device; possible to choose GSM-channel based on sender name; channels engaged consequently from #1 to the last one and again start from #1; it is possible to route SMS to channels based on recipient phone number prefix





AT-commands (Device as pool of Ethernet-modems. Receive/Send SMS)
- via TCP/IP and АТ-commands you obtain full control over each channel of the gateway. Each GSM-channel is accessible via IP-address:port





Email-to-SMS/SMS-to-Email (Device receives emails and sends as SMS, receives SMS and sends as emails. Receive/Send SMS)
- connection to external POP3-server (i.e. gmail). Receiving new e-mails and forwarding as SMS to the recipient indicated in the subject
- connection to external SMTP-server (i.e. gmail). Receiving new SMS and forwarding to e-mail recipient, indicated in GSM-channel settings





SMS-via-SIP/Simple SIP protocol (GSM-board controlled by Asterisk. Receive/Send SMS)
- it is possible to setup Simple SIP support and VoIP concurrently by additional settings on an Asterisk server and by using featured software on the client device





Flat-file database SQLite (GSM-board controlled by Asterisk. Receive/Send SMS)
- via SQLite database located on Asterisk server, it is possible to read incoming SMS and place SMS-records for sending by interacting with appropriate DB tables





HTTP-protocol and other ways (on incoming SMS or on incoming Call, device executes user script (bash, PHP, …) located in Linux file-system of the Gateway device. Receive SMS and Call notifications)
- there is a sample bash-script present for automatic sending incoming SMS to external IP-address (or Host) as a JSON-object by executing Curl command. There is a restriction for SMS body length – 100 symbols.





With third-party software:
- it is possible to interact with GSM-channels of gateway as with local COM-ports
- the device can be connected as one or several GSM-channels to server software
- on-board OS Linux allows to install additional software and extend functionality of the device
There are many Free and Commercial SMS-software available. Send us request to obtain our latest SMS-related software shortlist.





With SIM-bank/SIM-server solution:
- even with small gateway it is possible to use hundreds of SIM-cards comfortable
- it is possible to make balance control for SIM-cards and SIM-card replacement automatic
- SIM-card commutation is controllable via API-interface of the SIM-server software in “manual commutation” mode
- various aspects of SIM-server functionality are controllable via extensive SIM-Server API



Please contact us for remote testing and ordering directly in manufacturing company Polygator.



Updated SMS-module of the GSM-gateway

Updated SMS-module of the GSM-gateway

Updated version of the SMS-module allows routing SMS by a prefix of recipient number. Routing is possible to channel or group of channels associated with the prefix (one or several).


For example, if you assign prefixes (063) and (093) to a group of channels, it will result in sending all SMS with (063) and (093) prefixes via this channel group. Load balancing between channels done automatically – channels engaged continuously, from first to last and again from first. In addition, you can set daily SMS-sending limits each channel and connect to devices to SIM-card mass storage devices (SIM-server and SIM-bank).





Updated GSM-Combiner (8-1) at new price

Updated GSM-Combiner 8-1 at new price

Updated model of the GSM-combiner is available for ordering. New model has smaller size and improved characteristics. The 8-to-1 GSM-combiner able to mix up to 8 antennas to single cable (feeder).


Standard set includes:


- 8-to-1 GSM-combiner
- 8 SMA-connector patch cords, 50 cm each
- 10 m feeder (SMA-connector) with YAGI antenna


The Combiner has no special limitations for device compatibility. It and can be used with any Polygator equipment as well as with equipment of other manufacturers.


Updated model of the GSM-combiner is about 30% less expensive when previous model thanks to optimized manufacturing cycle.


Product page GSM-combiner 8-to-1



The 32 to 4 channels version is also available.

Updated pricing for GSM-cards (Linux, Asterisk)

Updated pricing for GSM-cards (Linux, Asterisk)



Multichannel PCI GSM-boards are available at new prices. A GSM-card for 4 or 8 channels (SIM-cards), allow to create GSM-gateway based on a regular PC with one or several PCI-slots.



GSM-cards can be installed inside a PC with Asterisk for Linux or Elastix.

This way you can create multichannel, scalable VoIP-GSM gateway or SMS-GSM gateway. You can install several cards in a single chassis.



There are some possible GSM-card usage scenarios possible:



1) Voice and/or SMS-gateway controlled by an Asterisk (dial-plan and asterisk console are supported, as well as command line (Bash). Features like IMEI-change and others are also supported.)
2) Voice and/or SMS-gateway controlled by Software “Polygator GSM-Gateway” with the support of the SIM-Server features
3) SMS-gateway (AT-command mode) under control of Polygator driver and SIM-Server support



Using the card under Asterisk is very easy and safe way to create GSM-gateway or SMS-gateway with further scaling opportunity.



To receive an updated price-list and additional information, please send request to This email address is being protected from spambots. You need JavaScript enabled to view it.

Polygator products at Miktorik User Meeting (Madrid, Spain)

At the end of last week October 16th 2015 in Madrid there was an event for partners and clients of Mikrotik company - Miktorik User Meeting. There were suppliers, integrators and users of solutions containing Mikrotik equipment.



One of the exhibitors was Spanish company WISPControl- system integrator and distributor of Polygator products. There were various models of Polygator PDUs presented at the company’s booth. GSM-sockets (PDU) Polygator, controlled via GSM-network, are the part of the solution for Internet providers (ISP), offered by our Spanish partner – WISPControl company.



Polygator products at Miktorik User Meeting Madrid, Spain



Polygator products at Mikrotik User Meeting (Madrid, Spain)

Our development presented at "elcom" exhibition (Kyiv, Ukraine)

Our development presented at Innotech exhibition (Kyiv, Ukraine)

The sample working device for power lines monitoring is presented on the exhibition “elcom” (April 21-24, 2015, Kyiv, Ukraine). The device is installed on improved model of power line.



The device is moving along power lines and performs photo-shooting and video-recording. Collected data transferred for processing to analytical center. Data transfer is performed either by wireless and mobile networks, either by storing recordings internally.



Our development presented at elcom exhibition (Kyiv, Ukraine)



Video recording from the device moving along the power line

https://youtu.be/ervVd9AHQkQ



Developments of our company embedded in the device include:
- Processing unit of control device
- Mobile data transmission unit (4 combined channels 3G/GPRS)
- GPS-tracking and audio-control unit.



The device works as universal mobile video-surveillance system and can be applied in various domains.



Engineering is one of the main services offered by a Polygator company. Our developers and programmers execute various orders for custom development and manufacturing single units and finished electronic devices. You are welcome to meet us on exhibition and use our engineering services.



elcom 2015_polygator_booth







Special offer: "Wholesale GSM-termination Starter Kit"

Special offer: Wholesale GSM-termination Starter Kit

Please consider this limited-time "Wholesale GSM-termination Starter Kit" offer on special price.



The "Wholesale GSM-termination Starter Kit" offer includes:
- Two compact VoIP-GSM gateways G8 (8 channel each)
- Tree “Mikrotik” routers (for VPN on DHCP)
- SIM-bank for 100 SIM-cards
- VPS for running management software SIM-server (free for 1 year)



Some features of the system:
- support for SIP, SMS, VPN, IMEI change, etc.
- ability to move SIM-cards between gateways and GSM base stations
- automatic balance checking and balance recharging, flexible analysis of SIM-card status in GSM-network
- automatic replacement (rotation) of SIM-cards according to rules list (timers, network statuses)
- availability of API (Json) for management by custom software



Please consider this limited-time offer for quick-starting your Wholesale termination business right now. The system can be scaled by standard scaling means (additional GSM-gateways and SIM-banks) without any special limits according to standard licensing policy. License for SIM-server software is free for configuration of up to 5 devices (banks and gateways).



Please state shipment address in your feedback for providing you with the precise offer.

Our development presented at "Innotech" exhibition (Kyiv, Ukraine)

Our development presented at Innotech exhibition (Kyiv, Ukraine)

The sample working device for power lines monitoring is presented on the exhibition FIRST UKRAINIAN FORUM OF INNOVATION TECHNOLOGIES http://innotech.kiev.ua/en (April 9-11, 2015, Kyiv, Ukraine). The device is installed on model of power line.





Developments of our company embedded in the device include:
- Processing unit of control device
- Mobile data transmission unit (4 combined channels 3G/GPRS)
- GPS-tracking and audio-control unit.





Engineering is one of the main services offered by a Polygator company. Our developers and programmers execute various orders for custom development and manufacturing single units and finished electronic devices. You are welcome to meet us on exhibition and use our engineering services.



Video recording from the device moving along the power line

https://youtu.be/ervVd9AHQkQ









GSM-gateway with Asterisk v11 on-board

GSM-gateway with Asterisk v11 on-board

Thanks to the updated software module Polygator PGGSM (providing integration of radio-channels to Asterisk) the Asterisk v11 now can be installed directly on the GSM-gateway.


The integration module Polygator PGGSM provides GSM-gateway channels control via dial-plan and console of Asterisk, as well as command line of OS Linux.


All GSM-gateways Polygator are able to run Asterisk on-board, making it possible to use the gateway as standalone IP-PBX "all-in-one" as well as GSM-Gateway at the same time. Depending on the gateway software module type the highest on-board Asterisk version may vary. Currently, all gateways managed by “PGGSM” software support installation of Asterisk v11. All GSM-gateways managed by “Polygator GUI” software are able to run Asterisk up to v1.6.2.2 on-board.


In any case it is enough to run just one GSM-gateway box Polygator with Asterisk on-board to create the telephony server.


To have remote access (via SSH and WEB) to any of our devices or making remote testing, please write to This email address is being protected from spambots. You need JavaScript enabled to view it. .







Gateway reports about SMS or Call in JSON format

Gateway reports about SMS or Call in JSON format

One of gateway G8 and G20 features is the ability to execute tasks on certain events (incoming call or SMS). For example, on getting SMS the gateway can transfer to external server SMS sender number, SMS recipient number, message body, SMS-center time, etc.



They way how server contacted is defined in configuration files of the gateway. It can be HTTP-request by method GET, POST or transferring data in JSON-format by method POST. Absolute flexibility of gateway setup allows to perform any actions on events and transfer data in almost any format.



This feature enables to use gateway for testing Mobile operator services, to obtain information about the event very fast, etc.



For more details please contact by email This email address is being protected from spambots. You need JavaScript enabled to view it. , skype: polygator or via contacts on website.
