DID-numbers creation by means of GSM-gateway

DID-numbers creation by means of GSM-gateway

Any model of VoIP-GSM gateway Polygator can serve for a creation of DID-numbers out of regular SIM-cards. For this purpose, you do not need any additional software - just standalone device. All you need is to enable all necessary options via WEB GUI and type in target SIP-addresses for each channel (like This email address is being protected from spambots. You need JavaScript enabled to view it. ).



The device may bring more DID-numbers into the numbers pool of any existing DID-provider. At the same time, it may help new DID-providers to start the business.



Although DID-numbers in most cases stand for inbound calls, with the help of GSM-gateway Polygator it is possible to setup outgoing calls via SIM-cards corresponding to DID-numbers.



Features for receiving and sending SMS via corresponding SIM-cards are also available.



Contact us for additional information and remote testing.



SIM-server API for custom VoIP and SMS-solutions

SIM-server API for custom VoIP and SMS-solutions

The SIM-server enables a flexible approach to SIM-cards management in VoIP-solutions (voice) as well as in SMS-solutions. It allows avoiding physical SIM-cards insertion into GSM-gateways and replaces it by logical «virtual» insertion of SIM-cards in gateway’s channels. Use of SIM-server technology dramatically expands the sphere of application for GSM-gateways, opens new possibilities for system scaling and for solving new tasks.


The multifunctional API for SIM-server management is available. It supports two main operating modes – AUTO-commutation mode and MANUAL-commutation mode. In the AUTO mode, the system initiates commutation of free SIM-cards automatically according to parameters set in advance. In the MANUAL mode commutation made only after receiving a certain API-command. The API SIM-server enables user to build high complexity system and create solution for non-standard task.


The gateway connected to the SIM-server keeps its normal features working. It can be interacted by user or by third-party software via the same VoIP and SMS-protocols and the same way as when SIM-cards inserted directly in the device.





To receive a general consultation on SIM-server technology, its application for solving your task and for getting DEMO-access, please let us know by contacts on our website!

Saving on calls 2 times and more

Saving on calls 2 times and more

Cutting costs for outgoing calls is the one of main ways how GSM-gateways are applied. If your company is currently using landlines for outgoing calls to cell phones – you already could save!


Outgoing call SIM-card choosing automation for many years allows cutting costs and optimizing workflow in sales departments, call-centers, taxi, e-shops, etc. GSM-gateway device automatically chooses SIM-card with minimal rate and places call at “home network” rate or special GSM-operator rate.


For example, currently one of Ukraine GSM-operators offers special SIM-cards for installing inside GSM-gateways. Local call to any mobile phone via such SIM-card costs 0.5 UAH/min (incl.VAT), to numbers inside operators’ “home” network – 0.2 UAH/min (incl.VAT). Compare it to the cost of the same call via fixed line (landline) operator – 1.2 UAH/min (incl. VAT). The difference of more than two times creates the same size opportunity for saving.


In order to cut call cost, buy GSM-gateways Polygator (Elgato Communications) – devices developed to implement this efficient cost saving process in the company.


Equipment being developed and manufactured in Ukraine since 2000, accompanied with 2 year warranty and 1 year of free tech.support.









Update: SMPP multi-accounts in G8/G20 gateways

Update SMPP multi-accounts in G8/G20 gateways

Feature of sending, receiving of SMS and DLRs by means of SMPP is present in G8/G20 gateway since very first firmware versions. This way gateway acts as basic SMPP-server. One of the unique SMPP-server features provided by recent firmware updates is multiple account support.

Ability to create several SMPP-accounts in one gateway allow assigning GSM-channels explicitly to user-accounts. This feature enables you to split GSM-channels between remote users, give channels for rent etc.

Each user establishes independent SMPP bind (in transceiver mode) and exchange data with device by it. Each channel of gateway is able to work via SMPP and concurrently perform VoIP-GSM calls, as well as use virtual SIM-cards from SIM-Server solution.

SIM-server “QuickStart” has been added to the WIKI

SIM-server QuickStart has been added to the WIKI

SIM-server “QuickStart” manual has been added to website with documentation for Polygator products.



The document includes a step-by-step description to start a minimal set of hardware and software in order to enable the GSM-gateway obtain SIM-cards «virtually» from remote SIM-bank storage.


The Minimal set to create SIM-server complex includes: 1 GSM-gateway, 1 SIM-bank and Linux-server, with «Polygator SIM-server» software installed. The document lists the main steps to perform via SIM-server web-interface. Please note: SIM-server devices address space must provide «visibility» of all devices from SIM-server IP-address.

SMS-gateways Polygator: boxed G8/G20 and GSM-boards PCI/PCI-e

SMS-gateways Polygator: boxed G8/G20 and GSM-boards PCI/PCI-e

SMS-gateways Polygator are able to provide full-featured processing of Incoming/Outgoing SMS, delivery reports and USSD-commands support. Standalone SMS-gateway G8/G20 enables from 4 to 24 SIM-cards available in GSM-network concurrently. By using PCI/PCI-e GSM-boards it is possible to achieve much more SIM-cards per one device ratio. Currently SMS-gateways Polygator support following protocols and scenarios (but not limited to):





SMPP (Device as SMPP-server. Receive/Send SMS)
- single SMPP login/pass per device; possible to choose GSM-channel based on sender name; channels engaged consequently from #1 to the last one and again start from #1; it is possible to route SMS to channels based on recipient phone number prefix





AT-commands (Device as pool of Ethernet-modems. Receive/Send SMS)
- via TCP/IP and АТ-commands you obtain full control over each channel of the gateway. Each GSM-channel is accessible via IP-address:port





Email-to-SMS/SMS-to-Email (Device receives emails and sends as SMS, receives SMS and sends as emails. Receive/Send SMS)
- connection to external POP3-server (i.e. gmail). Receiving new e-mails and forwarding as SMS to the recipient indicated in the subject
- connection to external SMTP-server (i.e. gmail). Receiving new SMS and forwarding to e-mail recipient, indicated in GSM-channel settings





SMS-via-SIP/Simple SIP protocol (GSM-board controlled by Asterisk. Receive/Send SMS)
- it is possible to setup Simple SIP support and VoIP concurrently by additional settings on an Asterisk server and by using featured software on the client device





Flat-file database SQLite (GSM-board controlled by Asterisk. Receive/Send SMS)
- via SQLite database located on Asterisk server, it is possible to read incoming SMS and place SMS-records for sending by interacting with appropriate DB tables





HTTP-protocol and other ways (on incoming SMS or on incoming Call, device executes user script (bash, PHP, …) located in Linux file-system of the Gateway device. Receive SMS and Call notifications)
- there is a sample bash-script present for automatic sending incoming SMS to external IP-address (or Host) as a JSON-object by executing Curl command. There is a restriction for SMS body length – 100 symbols.





With third-party software:
- it is possible to interact with GSM-channels of gateway as with local COM-ports
- the device can be connected as one or several GSM-channels to server software
- on-board OS Linux allows to install additional software and extend functionality of the device
There are many Free and Commercial SMS-software available. Send us request to obtain our latest SMS-related software shortlist.





With SIM-bank/SIM-server solution:
- even with small gateway it is possible to use hundreds of SIM-cards comfortable
- it is possible to make balance control for SIM-cards and SIM-card replacement automatic
- SIM-card commutation is controllable via API-interface of the SIM-server software in “manual commutation” mode
- various aspects of SIM-server functionality are controllable via extensive SIM-Server API



Please contact us for remote testing and ordering directly in manufacturing company Polygator.



How to find IP and other settings of the gateway?

Normally you would know an IP-address of the gateway on shipment or from referencing WIKI

However, what if you are getting back to the device sometimes later after certain changes was made?


One of the ways to acquire device setting is browsing system USB-flash on some computer.



How to find IP and other settings of the gateway?



The system USB-flash is formatted as ReiserFS so you can read it anywhere just by installing supporting software. Of course, you should avoid re-formatting USB-flash and performing any disk-checks, as may be advised by some host OSes. You absolutely need to keep it as original. Further, with the help of certain Win/Mac/Linux utilities you can reach any files for reading.


For example, on Windows you can use DiskInternals Freeware Linux Reader or YAReG.

How to find IP and other settings of the gateway?



To find an IP-address of the GSM-gateway you navigate to /etc/rc.d/rc.network and browse the rc.network file until you see "echo LAN mode" text. This section lists your current network settings.


The same way you can jump to config-files of native SIP-client (SipUA) as well as to Asterisk main config-files such as extensions.conf and sip.conf.

Updated GSM-Combiner (8-1) at new price

Updated GSM-Combiner 8-1 at new price

Updated model of the GSM-combiner is available for ordering. New model has smaller size and improved characteristics. The 8-to-1 GSM-combiner able to mix up to 8 antennas to single cable (feeder).


Standard set includes:


- 8-to-1 GSM-combiner
- 8 SMA-connector patch cords, 50 cm each
- 10 m feeder (SMA-connector) with YAGI antenna


The Combiner has no special limitations for device compatibility. It and can be used with any Polygator equipment as well as with equipment of other manufacturers.


Updated model of the GSM-combiner is about 30% less expensive when previous model thanks to optimized manufacturing cycle.


Product page GSM-combiner 8-to-1



The 32 to 4 channels version is also available.

SMS via SIP/Simple with GSM-card Polygator

SMS via SIP/Simple with GSM-card Polygator

For users of PCI/PCI-e GSM-boards Polygator under IP-PBX Asterisk it is possible to use SIP/Simple protocol for SMS messaging.


The SIP/Simple implements instant messaging via SIP.


Wikipedia link



The Asterisk-module of GSM-board Polygator implements its SMS-features via an Asterisk dial-plan that is why there is a way to setup receiving/sending SMS via the Simple protocol.


By using this feature, it is possible to turn a smartphone or even tablet PC without GSM-module into full-featured terminal for GSM-calls and SMS.



Polygator products at Miktorik User Meeting (Madrid, Spain)

At the end of last week October 16th 2015 in Madrid there was an event for partners and clients of Mikrotik company - Miktorik User Meeting. There were suppliers, integrators and users of solutions containing Mikrotik equipment.



One of the exhibitors was Spanish company WISPControl- system integrator and distributor of Polygator products. There were various models of Polygator PDUs presented at the company’s booth. GSM-sockets (PDU) Polygator, controlled via GSM-network, are the part of the solution for Internet providers (ISP), offered by our Spanish partner – WISPControl company.



Polygator products at Miktorik User Meeting Madrid, Spain



Polygator products at Mikrotik User Meeting (Madrid, Spain)
